Hot Water Boiler Generator
PT.INDIRA DWI MIITRA A company that is developing for the fabrication of hot water boilers to meet the needs of industry, hospitals and hotels that require a water heater as needed with an economical value while our capacity adjusts according to customer orders (custom)
Hot water heater is a heater using Thermal water fluid as a heat conductor and can work up to a temperature of 50 to 95 degrees Celsius. Hot water boilers work only at circulating pump pressure, so they are very safe and tools that require heating do not need to be designed with special construction. The working life of the Thermal hot water boiler used is generally more than 10 to 15 years and no additions are needed as long as there are no leaks in the pipes or heating equipment, and during that time no cleaning is needed because the inside of the coil is circulated by hot water.
What are the advantages of hot water boilers
Precise temperature control
No need for water treatment etc. chemicals that require high costs No heat losses from condensate and blow down like in a steam boiler
Low corrosion rate because there is circulation on the inside of the Boiler
Hot water heater is a heater using Thermal water fluid as a heat conductor and can work up to a temperature of 50 to 95 degrees Celsius. Hot water boilers work only at circulating pump pressure, so they are very safe and tools that require heating do not need to be designed with special construction. The working life of the Thermal hot water boiler used is generally more than 10 to 15 years and no additions are needed as long as there are no leaks in the pipes or heating equipment, and during that time no cleaning is needed because the inside of the coil is circulated by hot water.
What are the advantages of hot water boilers
Precise temperature control
No need for water treatment etc. chemicals that require high costs No heat losses from condensate and blow down like in a steam boiler
Low corrosion rate because there is circulation on the inside of the Boiler
Very low maintenance costs
• Full Automatic operation and easy so that it does not require an operator
Very low maintenance costs
• Full Automatic operation and easy so that it does not require an operator
As for the pen system support tools
Expantion Tank
The expansion tank serves to accommodate the expansion of the heating fluid, remove the air trapped in the installation and prevent capitation in the circulation pump.
Circulasi pump
The circulation pump functions to drain the heating fluid in the installation. The size and capacity of the pump is adjusted to the required capacity.
The pump capacity determines the shape of the heating fluid flow in the coil. The flow in the thermal must be turbolent, this is useful to avoid damage to the heating fluid and coil in the hotwater boiler.
The circulation pump that we use uses the KSB brand and can operate up to a temperature of 200 deg C.
Safety Device
Digital temperatur controls,Flow control switch,Automatic burner contro,Chimney temperatur control,Pressure guage,Pilot lamp indocator,Alarm dan emergency stop
•The entire installation must be filled with liquid so that the level control on the expansion tank.
The circulation pump will drain the heating fluid from the expansion tank to the body of the hot water boiler then transferred to the porcelain and back again to the expansion tank.
After the liquid circulation flow is stable, the burner will light up and burn the coil inside the coil heater body so that the heating fluid becomes hot and the heat is flowed to the tanker hatch process.
After the desired temperature is reached for example 50 deg C, the burner will automatically turn off and will turn on again after the temperature has decreased (eg the minimum setpoint temperature of 35 deg C the burner will automatically light up)
From the results of calculations that we have done on the Permata Sukses tanker, the thermal oil boiler capacity is 200.000kcal/h. Hot water system circulating hot liquids at a water pump flow rate of 100 m3/hour (30 HP motor power) to heat Crude oil / CPO with a capacity of 5,000,000 tons with a set point temperature of 35 deg C, loading 50 deg C, takes approximately 4 days/ 96 hours. (travel route for Pertamina Plaju Palembang to Pertamina Pontianak.
As for the temperature ups for faster route travel, the required capacity can be calculated. And customized
